dimanche 26 janvier 2020

Tractor day 7


After a day and a bit of further cleaning, lubrication and re-assembly the engine is more a less ready. The clutch should arrive sometime tomorrow and once I've re-borrowed the 46mm socket and breaker to reassemble it, I can reattach it to the tractor, fill up with oil and fuel and see if she starts and runs!

vendredi 17 janvier 2020

Tractor day 5/6

Works were delayed by the need to remove the clutch plate and housing which required a 46mm socket and breaker bar. The local tractor dealer "Dijeau" kindly lent me one overnight and the following day I was finally able to remove the engine from the tractor, move it into the shed and open the crankcase.

On inspecting the crankshaft, the damage doesn't seem as bad as I had at first feared, with only one of the connecting rod journals affected. The inner lining of the shell had melted over it and a few lumps were stuck to it. The material is much softer than the crankshaft and once the lumps had been removed I was able to re-polish the journal back to the original metal by using some 400 grit emery cloth, a flat shoelace wrapped around that to even the pressure and plenty of WD40. A bit of 600 cloth and it has a mirror finish.

Asvarta in Spain hold all the spares for ruggerini engines so I've been able to get a full gasket and seals set, filters, shell bearings, oil pressure sensor, injector seat washers and crank shaft seals (the one facing the clutch had failed). All for under 200 euros, so I'm feeling more hopeful of a positive outcome.

Spent the morning cleaning everything, so now I must wait for the parts before reassembling and calibrating the engine.





The clutch disc central friction plate is partially broken, I found parts of it in the bottom of the clutch housing, which explains the vicious clutch and stiff gears I've always had on the tractor. Valeo no longer make the clutch disc (the tractor is 34 years old) but amazingly I just found one on ebay still in its vacuum sealed wrapper!

mercredi 15 janvier 2020

Cirque de Cagateille


A wander up into the Cirque de Cagateille with Sheri and Michiel. We hadn't planned on a long day, it's been sub-zero at night and the cirque gets little sun. We had two vague ideas - either head up to the Etang de la Hillette or take the little path that heads left two thirds of the way up the headwall to reach the Etang de Piède. We opted for the latter because none of us had done it before!

Waterfalls all frozen but not enough ice for good climbing

  The steep climb up the headwall

The left path continues to climb steeply through the forest crossing below the arête of Mont Terquet (below the Pointe de la Hillette) before emerging from the trees at about 1600m. Shortly after we hit the snow. 5 cm of relatively fresh stuff on top of iron hard névé or water ice. The path was quickly buried under a slope sat at about 35 degrees. I went ahead with ice axe and crampons and was soon forced to front point up an increasingly exposed and icy slope. I reached the water ice in the photo below, where I decided onward progress was too difficult and dangerous without rope protection, plus we only had two axes between four of us.


We turned around and headed back into the forest for lunch.



A bit of a disappointing sunless day...but snow is coming!!



lundi 13 janvier 2020

Tractor day 4

Only a few hours on the tractor today as I had architecture work to do. Some problems trying to get the flywheel off, but in the end I made a flywheel puller from some steel angle and bolts and eventually after some "hammer persuasion" it came off. Engine plate, alternator, starting motor, hydraulic pump, etc removed. Tomorrow I should be able to remove what's left of the engine from the tractor and get it into the workshop to finally remove the crankshaft.

dimanche 12 janvier 2020

Tractor day 3

 head pistons and cylinders removed

One of the connecting rod shells (cousinettes) had overheated and melted over the crankshaft. Hopefully I can get this machined off to save having to buy a new crankshaft at 1350 euros!

The rest of the engine

samedi 11 janvier 2020

Tractor day 2

The morning was spent restocking our firewood in the house, which took longer without the tractor. After finishing the bobbins for Susie's spinning wheel (I've been waiting since Christmas for some brass tube to arrive), it was time to press on with the tractor again.

After checking that the hydraulic pump hadn't seized as this might have been blocking the engine from turning, it was time to attack the main engine. A lot of bits to remove before I could get to the head. The injectors, rocker arms, fuel lines, exhaust manifold (very choked with carbon inside), air intake and lots of other bits of bodywork and support. I took off the first head (it's a 2 cylinder 2 litre engine). Thankfully the cylinder and piston both look OK, the connecting rod bearing was stuck, it'll need to be replaced and after removing it the engine is turning. Still have to inspect the crankshaft for damage but at first glance its looks OK.

Things are looking more hopeful. If I just need to clean and rebuild, replacing gaskets, copper washers, the oil pressure sensor, the connecting rod bearings, oil and filters. I could get away with 150 euros of parts and 4-5 days of work. I'll find out for sure tomorrow.

vendredi 10 janvier 2020

Tractor problems

The tractor (an Antonio Carraro Tigre 2700) is probably our most useful tool. It transports our firewood, hay, building materials, etc, cuts the fields, makes hay, harrows, pulls cars out of ditches, fallen trees out of the fields, and mulches branches.

On Wednesday it sudden died whilst operating the mulcher. After a couple of tries at restarting it seized.

After removing the sump and some other exploratory work it seems the oil pressure sensor was broken and so I didn't notice it was low on oil - the oil pump may also have failed. Crankshaft looks OK from underneath.  The next step is to take off the head and see how bad the damage is internally. Hoping I can rebuild the engine if the head isn't damaged.

The engine a ruggerini RD220 isn't made anymore, though parts are still available. Haven't been able to find any reconditioned engines on-line.
